12
Removing and cleaning the nozzle
Lift the nozzle release
clip and pull the nozzle
forward to remove.
Rinse the nozzle under
warm water (max 40�C) to
remove dirt/debris.
Remove both tanks and tilt
the machine back.
Push the nozzle backwards
until it clicks into place.
To replace the nozzle align
the tabs at the top of the
nozzle with the machine.
IMPORTANT: Carpets should be dry vacuumed thoroughly before washing. This will prevent
excessive build up of dirt/debris in the nozzle. If the nozzle is fitted incorrectly, this will cause
poor dirty water pick up.
Removing and emptying the solution tank
Twist the solution tank cap
anticlockwise and remove.
Pull up the solution tank
and lift to remove.
Pour unused solution into
the solution bottle.
Twist the solution tank
cap clockwise until tight.
To replace, slide and push
the solution tank firmly
into the machine.
Cleaning and maintenance
