Vax V-100T - Parts Overview

2 pc extension tube
Flexible hose
Combination floor tool
Castor wheels
Top cover retainer clips
Post-motor filter (at rear)
Power cord
On/off button
Carry handle
Dusting brush
Crevice tool
Upholstery tool
Dust bags (x3)
IMPORTANT: The accessories are stored in the dust bag compartment and need to be removed before operating
the vacuum cleaner.
2
6
Parts Overview
1. Parts Overview
Fig. 1/1
9
8
7
5
2
1
3
4
13
10 11 12
1
2
3
4
5
6
7
8
13
12
11
10
9
