VBM DOMOBAR JUNIOR DIGITAL - Component Identification; Machine Component Overview

14
16
13
1
8
11
14
15
17
7
9
10
12
2 4
3 6 5
ENG
4,
COMPONENT IDENTIFICATION.
1 Luminous main switch “ON/OFF”.
2 Machine status LED.
3 ECO mode “ON/OFF” LED key.
4 Led key for coffee temperature increase.
5 Led key for coffee temperature
decrease.
6 Display.
7 Spear steam.
8 Spear hot water.
9 Steam supply control handle.
10 Hot water supply control handle.
11 Coffee dispensing lever.
12 Coffee dispensing group.
13 Shelf holding surface.
14 Removable drip tray.
15 Bowl liquid level float.
16 Water tank cover.
17 Filter holder.
