VBOX 3i - Motorola Format

VB3i CAN Output
The VBOX 3i has a CAN output which is present on the 5-way connector output.
Note: Channels highlighted in BLUE are present on Dual Antenna systems only.
The CAN outputs for ADAS Modes are available below:
• 1 Target Vehicle
• 2 Target Vehicles
• 3 Target Vehicles
• Static Point
• Lane Departure Warning
• Multiple Static Points
Motorola Format
Data format: Motorola
Baud rate: 500 kbit/s
Channel definitions are available here.
ID*
Data Bytes
1 2 3 4 5 6 7 8
0x301
(1)
Satellites
(2) Time_Since_Midnight _UTC (3) Position_Latitude
0x302 (4) Position_Longitude (5) Speed (kts) (6) Heading (°)
0x303 (7) Altitude (m)
(8) Vertical_Velocity
(ms)
Unused
(9)
Status_1
(10)
Status_2
0x304 (11) Trigger_Distance (m)
(12)
Longitudinal_Acceleration
(g)
(13)
Lateral_Acceleration
(g)
