VBOX 3i - VB3 i Technical Specifications

VB3i Technical Specification
All specifications refer to the most current VBOX 3i models, specifications for older models can be viewed
within legacy datasheets on the VBOX Automotive Website.
GPS Specifications
Velocity
Accuracy 0.1 km/h (averaged over 4 samples)
Units km/h or mph
Update Rate 100 Hz
Maximum Velocity 1000 mph
Minimum Velocity 0.1 km/h
Resolution 0.01 km/h
Latency
(more information available here)
• Minimum: 4 ms/ 8.5 ms (±1 ms)
• Fixed, no IMU integration: 15.5 ms/ 20 ms
• Fixed, with IMU integration: 20 ms
Distance
Accuracy 0.05 % (<50 cm per km)
