9
1) Display: Backlit, 128 × 64 pixel display with contrast adjustment
2) Operating Temperature: 0 to 60°C (32 to 140 F°)
3) Storage Temperature: -20 to 70°C (-4 to 158 F°)
4) External Power: 8.0 to 18.0 V power provided via vehicle battery
5) Dimensions
3.2 Specifications
3.3 Included
3.4 Welcome
1) VD10 Scan Tool main unit
2) User’s Manua
in menu mode. When more than one screen of data is retrieved, moves down
through the current screen to next screens for additional data.
6.OBD II CONNECTOR – Connects the scan tool to the vehicle’s Data Link
5.DOWN SCROLL BUTTON – Moves down through menu and submenu items
3.5 Battery Tester
Welcome to use this OBD tester, it will display a [welcome] menu first. Please
turn the ignition on. Press the ENTER button to continue.
Connector (DLC).
Length
Width Height
70mm 22mm 126mm
Welcome
Please turn the ignition on
ENTER to continue
11
3.7 About
From the About menu, show the software version, hardware version and serial
number of product.
2) From the Unit of Measure menu, use the UP/DOWN scroll button to select
the desired Unit of Measure. the Default is Metric unit.
3) Press the ENTER button to save your selection and return to the previous
menu.
Unit of Measure
English
Metric
1/2
10
3.6 Setup
From the Main Menu, use the UP/DOWN scroll button to select Setup, and
press ENTER.
From the Setup menu, use the UP/DOWN scroll button to select language, and
press ENTER to language menu to select dierent languages.
1) From the Main Menu, use the UP/DOWN scroll button to select the Battery
Tester and press the ENTER button.
2) From the Battery Test menu, display current voltage of battery and reference
information, press the EXIT button to exit to the previous menu.
Main Menu
Diagnostics
Battery Tester
Setup
About
2/4
Main Menu
Diagnostics
Battery Tester
Setup
About
2/4
Setup
Language
Unit of Measure
1/2
3.6.1 Language
1) From the Setup menu, use the UP/DOWN scroll button to select Unit of
Measure, and press ENTER.
Setup
Language
Unit of Measure
1/2
3.6.2 Unit of Measure
6
5
3
8
3.Using the Scan Tool
3.1 Tool Description - OBD VD10
2
1
4
1.LCD DISPLAY – Indicates test results. Backlit, 128 x 64 pixel display with
menu mode. When more than one screen of data is retrieved, moves up through
the current screen to the previous screens for additional data.
3.EXIT BUTTON – Cancels a selection (or action) from a menu or returns to
4.UP SCROLL BUTTON – Moves up through menu and submenu items in menu
2.ENTER BUTTON – Confirms a selection (or action) from a menu.
contrast adjustment.
the menu. It is also used to exit DTC Lookup screen.
