VDO CH0600, CH1000 User Manual

4
SHOCK ABSORBER ADJUSTMENT
The CD changer is pre-set at the factory for horizontal mounting (Fig. 7).
If you mount the CD changer horizontally no adjustment is needed. In this case go to the next
section “MOUNTING”.
If you mount the CD changer vertically, or at a 45° angle, (or if you later change the mounting
angle) you must first change the shock absorber setting.
• Change the position of the setting mechanisms at both sides of the CD changer using a
screwdriver.
• For vertical mounting, use position “V” (Fig. 8).
• For mounting at an angle of approx. 45°, use position “45°” (Fig. 9).
After setting the position of the shock absorbers, glue the supplied stickers G over the holes
of the setting mechanisms (CH1000 only).
CH0600/1000 GB 30/07/99 14:00 Page 4
