Technical data
Measuring principle: Utrasonic running-time mesurement
Application range: 0.5 to 120 m depending on ground
and installation conditions
Frequency: 200 kHz
Supply voltage: 10.8 V ... 32 V DC
Current consumption: Display unit: about 90 mA at 12 V DC
without illumination, about 250 mA with
illumination
Echo sounder:about 50 mA at 12 V DC
Transmitter power: about 40 Wrms, about 320 Wpp
Operating temperature: -10 °C to +60 °C
Type of protection: DIN 40050 - IP 65 at front, IEC 529
EMC protection: CE: EN 50081-1, EN 50082-1
Dimensions: Indicating instrument:
Front ring diameter 105 mm
Installation diameter 86 mm
Installation depth 56 mm (union nut)
Installation depth 90 mm (bracket)
Sounder / Hull sleeve:
Installation diameter: 53 mm
Maximum hull thickness: 36 mm
For internal installation:
Maximum hull thickness: 12 mm
Technical modifications reserved
