GB
45
Required DLD
®
Wide Range II
connections
• Connection to the power supply
• Connection to the ignition signal and to earth
• Connection to download the data via:
- the CAN interface or
- K-Line interface (accessory)
DLD
®
Wide Range II installation
locations
You can choose the installation location. We recommend,
however, that you install the device into the dashboard, in the
vicinity of the tachograph.
Please also note the following warnings and instructions:
Warning: Do not cover any defroster vents on the dashboard
with the DLD
®
Wide Range II and note any other devices
(in the background) before fi xing the device.
Note: In compliance with §35b StVZO (German Road Traffi c
Licensing Regulations), the driver must have a suffi cient fi eld
of vision under all operating and weather conditions.
Note: If DLD
®
Wide Range II is to be installed in locations
where higher requirements must be met (presence of humidity,
vapour, oil, etc.), the device should be installed with the
connection strip facing down.
