VDO DLD Wide Range II - Optional: Connecting the DLD Wide Range II to the K-Line interface; DLD Wide Range II - LED indicators; GPS recording

GB
49
Page 8 also shows the activated termination resistor
(status upon delivery) and the DIP switch location.
Optional: Connecting the DLD
®
Wide Range II
to the K-Line interface
The K-Line communication cable (see page 9) is not included
in the package. Please contact your service partner.
DLD
®
Wide Range II – LED indicators
Please refer to page 9 for information about
DLD
®
Wide Range II LED indicator locations (incl. status).
GPS recording
If you also want to record GPS data with the
DLD
®
Wide Range II, you must connect an external antenna.
A GPS antenna is not included in the package. Please contact
your service partner.
