LedSync820C Users Manual Vegas LED Screens
---------------------------------------------------------------------------------------------------
VEGAS LED SCREENS - LED VIDEO PROCESSOR
16
VI. Specifications
Inputs
Nums/Type
1×RGBHV(VGA)
1×DVI
1×YPbPr(HDTV)
4×CVBS
1×Y/C(S-Video)
Video system
PAL/NTSC
CVBS Scope/Impedance
1V (p_p) / 75Ω
Y/C Scope/Impedance
Y: 0.7V (p_p) / 75Ω,
C: 0.35V (p_p) / 75Ω
RGB/DVI resolution
1280×1024@60Hz, 1024×768@60Hz ,
800×600@60Hz
RGB Scope/Impedance
0.7 V (p_p) / 75Ω
YPbPr (HDTV) System
1280×720p@60Hz, 1920×1080i@60Hz
YPbPr (HDTV)
Scope/Impedance
Y: -0.3V ~ +0.7V (p_p) / 75Ω
Pb: -0.35V ~ +0.35V (p_p) / 75Ω
Pr: -0.35V ~ +0.35V (p_p) / 75Ω
Connectors
RGBHV: 15pin D_Sub(female)
DVI: 24+1 DVI_D
YPbPr(HDTV): RCA×3
CVBS: RCA
Y/C: 4pin mini DIN(female)
Outputs
Nums/Type
1×RGBHV
1×DVI
RGB/DVI resolution
1024×768@60Hz
RGB Scope/Impedance
0.7 V (p_p) / 75Ω
Connectors
RGBHV: 15pin D_Sub(female)
DVI: 24+1 DVI_D
Others
Control
RS 232. Panel Button
Power
100-240VAC 60W 50/60Hz
Operating Temp
5-40
Humidity
15-85%
Size
155 mm (high) ×350mm (wide) ×
485mm (length)
Weight
5.6 Kg
