27.14. The principle of input parameter, setting E.8 Auto Calculation means to tell
the unit LVP615 to crop how much of the input video source, and setting
the H or V start means to tell the unit LVP615 to crop the input video source
from where, the example as the picture below;
28. Example 8 LED 3840 x 1024
E. Mosaic ( Video wall App)
--------------------------------------------------------------------
E.9 In Width 576
E.10 In Height 1080
E.11 In H_Start 1344
E.12 In V_Start 0
E.13 Ouit Width 1536
E.14 Out Height 1024
E.15 Out H_Start 0
E.16 Out V_Start 0
