Vdwall LVP615 - Page 45

28.1. LED 5120 X 1024 composed by 3 LED screens LED1 LED2 and the
resolution of every LED screen: LED1 1920 x 1024, LED2 1920 x 1024;
28.2. When you open LVP615’s Mosaic function to splicing very bigger LED screen,
there are some conditions you need to consider:
9. Every processor must set same output resolution;
10.# 1 2 processor must open Mosaic function, press Mosaic key to open or
off the function;
11.After opening Mosaic # 1 2 processor only have Mosaic and PIP function;
12.The output resolution of PC must be as same as the output resolution of
processor, and at this example you only can connect DVI input source;
Setting output resolution
28.3. After opening processor press Setup key to enter setup menu, press Brt- to
select 1.Output Image, press OK to enter output image setup;
