28.8. Press Setup key to enter Mosaic setup menu, press Brt+ or Brt- key to select
setup option, rotate OK to change parameter, press OK to save parameters
(the step only for #1 #2 processor) ;
28.9. In menu the LED Total Width and LED Total Height must be as same as your
actual LED screen, at present the resolution of LED screen is 3840 x 1024;
28.10. In menu the Unit width and Unit height must be as same as the actual LED
screen the unit LVP615 connected;
28.11. After set these parameters of last two steps, press Brt+ or Brt- key to select
setup option E.8 Auto Calculation, press OK to calculate input parameters
automatically (the step only for #1 #2 processor);
Mosaic Input： DVI
In Status： 1080p
Input image Size： 1920 x 1080
Input image Start： ( 0, 0 )
--------------------------------------------------------------------
Mosaic Output Size： 1920 x 1080
Mosaic Output Start： ( 0, 0 )
Mosaic PIP: Off
--------------------------------------------------------------------
Device ID 1
E. Mosaic ( Video wall App)
--------------------------------------------------------------------
E.1 LED Total Width 3840
E.2 LED Total Height 1024
E.3 Unit Width 1920
E.4 Unit Height 1024
E.5 Unit H_Start 0
E.6 Unit V_Start 0
E.7 Sync. Mosaic Off
E.8 Auto Calculation OK to Apply
To Next Page
