28.12. After last step press press Brt+ or Brt- key to enter input parameter setup
menu ( normally for input parameters we only need to set In H_Start and In
V_Start, the step only for #1 #2 processor);
28.13. #1 processor
28.14. #2 processor
28.15. The principle of input parameter, setting E.8 Auto Calculation means to tell
the unit LVP615 to crop how much of the input video source, and setting
the H or V start means to tell the unit LVP615 to crop the input video source
from where;
E. Mosaic ( Video wall App)
--------------------------------------------------------------------
E.9 In Width 960
E.10 In Height 1080
E.11 In H_Start 0
E.12 In V_Start 0
E.13 Ouit Width 1920
E.14 Out Height 1024
E.15 Out H_Start 0
E.16 Out V_Start 0
E. Mosaic ( Video wall App)
--------------------------------------------------------------------
E.9 In Width 960
E.10 In Height 1080
E.11 In H_Start 960
E.12 In V_Start 0
E.13 Ouit Width 1920
E.14 Out Height 1024
E.15 Out H_Start 0
E.16 Out V_Start 0
