Veco Frigoboat W35F User Manual

19 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Frigoboat

Marine Refrigeration Systems

---------------------------------------------------------------

Installation & Instruction Manual

For All Models:

Air Cooled, Pumped-Water Cooled,

Keel Cooled, and Keel-plus-Air Cooled

(Systems using Secop (formally Danfoss) BD 35 or BD 50 compressors)

It is important to read this manual thoroughly before

installing and operating a Frigoboat system.

Veco NA

301.352.6962

info@veco-na.com

Rev 39 – 02/2019

Table of Contents

Questions and Answers:

M
Megan ScottAug 15, 2025
What to do if Veco Compressor attempts to start, then stops soon after?
- A
  Aaron FloresAug 15, 2025
  If your Veco Compressor starts and then stops, consider these potential causes: * **Power Supply**: The most likely cause is a faulty or inadequate power supply. Monitor the supply voltage at the controller's power terminals before, during, and after start attempts. It should not drop below threshold levels. Check the power supply, ground connections, wiring size and charge the batteries if necessary. * **Relay or Unauthorized Component**: A faulty fan or pump relay, or an unauthorized component, could be the issue. Remove the connectors from the F and + terminals on the controller and try restarting. Note the maximum current draw on these terminals is limited to 0.7 amps at 12v. * **Refrigerant Couplings**: Check that all refrigerant couplings are properly made.
A
andrea35Sep 2, 2025
How to prevent excessive frost build-up in my Veco Compressor system?
- D
  Dawn Richards MDSep 2, 2025
  To prevent excessive frost build-up in your Veco Compressor system, ensure that: * All drains and holes in the box are sealed. * If using a circulating fan, it's not too powerful and doesn't force cold air out of the box. * Door/lid seals are in good condition. Replace if necessary. A good seal should grip a dollar bill when closed. Apply masking tape to suspect areas after defrosting and check for frost build-up after several days to identify leaks.

Veco Frigoboat W35F Specifications

General

Type	Compressor
Model	W35F
Brand	Veco Frigoboat
Voltage	12/24 V DC
Compressor	Danfoss BD35F
Refrigerant	R134a
Nominal cooling power	350W @ 12V, 400W @ 24V

Summary

Chapter 4 K35F, K50F - Water cooled with Keel Cooler

4:1 Keel Cooler

Instructions for mounting the Keel Cooler through the hull.

4:2 Grounding and cleaning

Explains grounding, bonding, and cleaning procedures for the Keel Cooler.

Chapter 5 Danfoss or Secop Electronic Controller for Frigoboat systems

5:3 Fault Codes

Lists and explains various fault codes and their meanings.

5:4 LED Alarm Indicator - Diagnostic Diode

Explains the LED indicator for diagnostic purposes and fault conditions.

Chapter 6 Aluminum H-, F- and B-Type Evaporators (Horizontal, Flat, Bin Type)

6:3 Installation

Instructions for installing evaporator tubing and making connections.

Chapter 9 Quick Connect Refrigerant Fittings

9:1 Connecting the Quick Connect fittings

Provides step-by-step instructions for connecting Quick Connect fittings.

Chapter 10 Electrical

10:1 Power supply

10:4 Connections, Power

10:5 Connections, Mechanical Thermostat

Chapter 11 Troubleshooting Guide

11:1 Compressor not running, no start attempt

Lists probable causes and actions for compressor start issues.

11:2 Compressor attempts to start, or starts then stops soon after

Addresses issues where the compressor starts but stops shortly after.

11:3 System runs, box temperature too high

Diagnoses and resolves issues of high box temperature.

11:4 System runs, box temperature too low

Identifies causes and solutions for low box temperature.

11:5 Excessive frost build-up

Related product manuals

Veco Frigoboat K35F

Veco Frigoboat K50F

Veco Frigoboat Paris 35F

Veco Frigoboat Capri 35F
