TABLE 5-2
VALVE BLOCK ASSEMBLY
ITEM # VIC P/N DESCRIPTION
1 0137-200-00 Upper Valve Block
2 1890-284-00 Fine (Direct Valve)
0011-023-00 Replacement O-Ring, Fine Valve
3 0137-120-03 Vent Valve
0019-022-01 Replacement O-Ring, Vent Valve
4 1890-286-00 Rough Valve (100 -115V Systems)
1890-286-01 Rough Valve (230 - 240V Systems)
0011-028-00 Replacement O-ring, Rough Valve
5 1890-284-00 Fore-line (Reverse) Valve
0011-023-00 Replacement O-Ring, Fore-line Valve
6 1890-287-00 Gross Valve (available only on MS-40
with External Rough Pump Option Kit,
P/N 0137-805-00)
1331-776-00 Screw, Pan Head, M3 x .5, 45mm 1g
0019-014-00 Replacement O-Ring, Gross Valve Body
0019-006-01 Replacement O-Ring, Gross Valve Manifold
0019-013-01 Replacement O-Ring, Gross Valve Manifold
7 0137-208-00 Gross Restrictor Plate (with ext. rough)
0137-208-01 Blank Plate (no ext. rough)
Commercial Screw, Pan Head, M3 x .5, 8mm lg
8 0016-013-00 O-Ring, Gross Restrictor Plate
9 0011-006-00 O-Ring, Gross Restrictor Plate
10 1890-287-00 Sniff Valve
0019-014-00 Replacement O-Ring, Sniff Valve Body
0019-006-01 Replacement O-Ring, Sniff Valve Body
0019-013-01 Replacement O-Ring, Sniff Valve Body
Vacuum Instrument Corp.
2099 Ninth Avenue
Ronkonkoma, NY 11779
631.737.0900
1109-186-00 Rev. C 5-8
