Page 33
1
2
3
4
6
5
Changing The Printer Paper
The paper roll should be changed
when a red stripe appears on the
printouts.
A 4-roll pack of printer paper (Part
Number 514100-210) is available
from your Service Contractor.
Swing up the printer cover (1) and
push the paper feed release lever
(6) down. Notice the paper roll (3)
and paper feed guide (4).
If the take-up spool (2) has been
used, pull out the spool with the
printed reports and tear off the
paper close to the printer feed
roller(5).
2
8
7
9
Pull out the take-up spool (2) and
separate its two halves by pulling
them apart. Remove the printed
reports, but do not discard the
reports as they may be required
later.
Pull out the old paper roll (3) and
any remaining paper.
Remove the roll shaft (7) and
press it into the new roll (8).
Push the roll (8) into the lower
slots in the printer with the paper
tail (9) down and at the back.
