7
PROGRAMMING
PROGRAM MODE Continued
rCALP
r
Rate Calibration Factor Decimal Point
Function: Sets the decimal point position for the rate calibration factor display
Adjustment Range: 0 to 0.0000
Default Value: 0
c
count
Count Mode
Function: Defines how the input pulses will be applied to the count value
Adjustment Range:
dir
A+B: Inputs on both the
A & B channels
increment the total
Directional: When input
B is inactive, input A
increments. When input
B is active, input A
decrements
A+-
A-
A-B: Inputs on the A
channel increment the
total, while inputs on the
B channel decrement
Default Value: A+B
PGM
Input Type
Function: Programs the unit to match the electrical characteristics of the input signal
Adjustment Range:
i
1nPut
Sinking: The unit will
accept a NPN or dry
contact input which sinks
voltage to common
Sin
Src
Source: The unit will
accept an PNP input
which sources voltage
PGM
Default Value: Sinking
PGM
<>AG
Magnetic: The unit will
accept a magnetic input
from 0.5 to 30V peak
rCAL
Rate Calibration Factor
Function: Used to scale the input into engineering units by multiplying this value by the input frequency
Adjustment Range: 0.0001 to 99999
Default Value: 1
PGM
rdEc
E
Rate Decimal Point Position
Function: Sets the decimal point position for the rate display
Adjustment Range: 0 to 0.0000
Default Value: 0.0
PGM
r
.
bb
QuAd
Quadrature: The unit
accepts a phased input
from an encoder. The
total increments when the
A channel leads the B
channel
