8
PROGRAMMING
PROGRAM MODE Continued
P
Minimum Pulses
Function: Sets the minimum number of pulses to be received before the display will update the rate value.
Note: Display Update Time and Minimum Pulses must be realized before the display will update.
Adjustment Range: 1 to 99
Default Value: 10
PulS
PGM
S
Startup Suppression
Function: Determines the delay period that will occur after power-up before alarm operation is possible
Adjustment Range: 0 to 99 secs.
Default Value: 0
Strt
PGM
U
uPdAt
Display Update Time
Function: Sets the amount of time between display updates
Adjustment Range:
0.1
0.25
0.5
1
0.1 sec. 0.25 sec. 0.5 sec. 1 to 10 sec.
Default Value: 1
PGM
to 1 0
0
0
Display to Zero Time
Function: Displays minimum input frequency by setting the amount of time after no pulses are received, when
the display will show zero
Adjustment Range:
0.1
0.25
0.5
1
0.1 sec.
(10 Hz.)
0.25 sec.
(4 Hz.)
0.5 sec.
(2 Hz.)
1 to 10 sec.
(1 Hz. to 0.1 Hz.)
Default Value: 1
PGM
to 1 0
ti
Filter Speed
Function:
Enables the debounce filter of the meter to properly match the application
Adjustment Range:
F
SPEEd
20: The unit will accept up to 20
pulses per second. Generally
used with contact inputs to
eliminate false counts caused by
contact bounce
20
200
200: The unit will accept up to
200 pulses per second. Generally
used for higher speed contact
inputs or to filter noise on
electronic signals in low speed
applications
10000
10,000: The unit will accept up
to 10,000 pulses per second.
Generally used with high speed
electronic inputs and encoders
Default Value: 10000
PGM
www.TheTimerAndCounterCompany.com
