Veeder-Root Series C628 User Manual

9
PROGRAMMING
PROGRAM MODE Continued
r
Front Panel Reset Enable
Function: Determines whether the Front Panel Reset key can be used to reset the rate value
Adjustment Range:
rS
En
Enable: The rate value can be reset
while being viewed in Operation Mode by
pressing the Front Panel Reset Key
En
diS
Disabled: The Front Panel Reset Key is
disabled and the rate value can only be
reset through the Remote Reset Input
Default Value: Enable
PGM
c
Serial Communication Enabled
Function: Activates the RS-485 communication option board
Adjustment Range:
Co<>S
None: No communication
board installed
nonE
Fit
Default Value: If ordered from the factory with the RS-485 board, the default will be "fitted". If the board is
installed in the field, this parameter will need to be changed from its default of "none"
Fitted: A communication
board is installed in the
unit
PGM
t
Retransmission Enable/Select
Function: Determines whether a voltage/current is an output, and if so, which range
Adjustment Range:
nonE
0-5u
0-10u
0-20A
None
0-5 Volts 0-10 Volts 0-20 mA
Default Value: None
PGM
rt
En
4-20A
4-20 mA
L
Retransmission Scale Minimum (Appears only if a current/voltage is selected)
Function: Defines the lower end of the linear scale for the retransmission output by defining the value equated
to the minimum output signal - i.e. for a 4-20 mA output, this would be the value corresponding to 4 mA
Adjustment Range: 0 to 99999
Default Value: 0
PGM
rt
Lo
H
Retransmission Scale Maximum (Appears only if a current/voltage is selected)
Function: Defines the lower end of the linear scale for the retransmission output by defining the value equated
to the minimum output signal - i.e. for a 4-20 mA output, this would be the value corresponding to 20 mA
Adjustment Range: 0 to 99999
Default Value: 100
PGM
rt
Hi
