4 Diagnostics
The Diagnostic main screen gives you access (depending on installed features) to the site's current and historical
tank and line test results. Also from Diagnostic screens, you can manually run tank tests, PLLD line tests and view
technical data from monitored devices. Touch the Help button at the top of each diagnostic screen to view more
information on each screen’s contents.
From the Home Screen, touch Menu>Diagnostics to access the Diagnostics Main screen. To access specific
diagnostic information for the TLS-450PLUS, touch the desired diagnostic button. An overview of each diagnostic
component is discussed in the paragraphs below.
AccuChart
The AccuChart diagnostics contain information on the current and historical tank calibration test results.
AVAILABLE DIAGNOSTIC SCREENS
•
Calibration Feedback - This screen contains alarms and warnings that are only issued during the automatic
AccuChart calibration process.
• Data Sufficiency - This screen lets you view an histogram of the data collected at different levels of the tank
for the tank's calibration.
• Delivery Instructions - This screen contains instructions to help you achieve better calibration data over the
range of the tank
• Error Plot - This screen lets you view an error plot comparison of two charts using the same data from one
tank.
• Histogram - This screen lets you view an histogram comparison of two charts using the same data from one
tank.
• Time Ordered Sales - This report lists all tank sales volume calibrating records applied to two selectable tank
charts, over a selectable range, with variances displayed for each chart in adjoining columns.
BIR
The BIR diagnostics contain information on sales, deliveries and inventory levels to allow for reconciliation.
AVAILABLE DIAGNOSTIC SCREENS
•
Reconciliation - This screen reports metered sales, variance and suggested reasons for the variance for the
selected product.
• Status - This screen contains a list of causes for Reconciliation events.
LPR Sensor
The LPR (Line Pressure) Sensor diagnostics contain reports on the activity and condition of Line Pressure
Sensors.
To Next Page
