A-1
Appendix A: Site EVR/ISD Equipment Location Worksheet
You should create a table listing each hose, fueling point, Air Flow Meter’s serial number, etc.. This information will
be required when you perform the EVR/ISD Setup hose/meter dispenses. This appendix contains blank
worksheets for sites with single- and multi-hose dispensers. You are advised to fill in all of the appropriate
information about your installed equipment, complete the TLS console’s Hose Settings setup, then perform the
product meter ID dispensing setup procedure in “Hose Mapping - Assisted Mode” on page 21.
Single-Hose Fueling Position Dispensers
1
Each hose must have a unique number (1 - 99).
2
This is the Fuel Position Label which is the visible number on the outside of the dispenser (1 -2 digits).
3
The hose label is always Blend for single-hose dispensers.
4
The AFM ID number associated in Device Setup.
5
This is the serial number on the Air Flow Meter (1 per dispenser).
6
This is the AFM label entered in Device Setup (1 per dispenser and must be in the format shown, e.g., AFM FP1&2 - where 1 and 2 refer to
the one [or two] numbers on the outside of the dispenser).
7
After you have entered the contents of columns 1 - 5 enter as needed in Hose Settings setup, you now must follow Assist Mode Mapping
procedure and dispense from each gas meter AND one blend grade that feeds each hose. Enter a check beneath each product following a
dispense from the hose.
FILL OUT - USE TO SETUP HOSE TABLE Assist Mode Check List
Hose
ID
1
FP
2
Hose
Label
3
AFM ID
4
& AFM Serial Number
5
AFM Label
6
Product Dispense(s)
7
1st 2nd 3rd 4th
1 Blend
AFM FP__&__
2 Blend
3 Blend
AFM FP__&__
4 Blend
5 Blend
AFM FP__&__
6 Blend
7 Blend
AFM FP__&__
8 Blend
9 Blend
AFM FP__&__
10 Blend
11 Blend
AFM FP__&__
12 Blend
13 Blend
AFM FP__&__
14 Blend
15 Blend
AFM FP__&__
16 Blend
To Next Page
