Installation Guide National Electrical Code Compliance
8
Dimensions of the receiver, transmitter, repeater, and battery housing are shown in Figure 4.
Figure 4. Wireless component dimensions
LEGEND FOR NUMBERED BOXES IN FIGURE 4
1. Receiver, transmitter, and repeater dimensions 2. Battery housing dimensions
