Veeder-Root TLS-450 PLUS - Table 1 - Confi Gurable (C); Non-Confi Gurable (NC) Ports for Comm Modules in Comm Slots 1-3

Page 6
Comm Module
Comm
Type
Slot 1 Slot 2 Slot 3
Port Port Port
121212
RS-232 Single Port (also EDIM, Satellite S-SAT and Satellite H-JBox apps.)
Serial
NC C NC C NC C
RS-232 Dual Port (also EDIM, Satellite S-SAT and Satellite H-JBox apps.)
C C C C NC C
RS-485 Single Port
NC C NC C NC C
RS-485 Dual Port
C C C C NC C
RS-232/RS-485 Dual Port
C
(RS232)
C
(RS485)
C
(RS232)
C
(RS485)
NC C (RS485)
SiteFax / Modem
NC C NC C NC N
CDIM
DIM C NC C NC
Table 1 - Confi gurable (C) / Non-Confi gurable (NC) Ports For Comm Modules In Comm Slots 1-3
