4. VeeCAN 128 Installation
Units are designed to be mounted onto a bulkhead, dashboard, or panel.
The method is described below. The only required components are
the mounting bracket and hardware; these are supplied with every
VeeCAN 128 unit.
™
Instructions:
Decide on a location.
Allow adequate clearance behind the display for cable connection
(to ensure that the cables are not unduly stressed), and for ventilation.
Leave sufficient cable so that the unit may be removed for servicing.
Cut a 2 inch (51 mm) hole.
Screw the studs into the rear case.
Place the VeeCAN 128 in position, use the mounting bracket and
thumb nuts to secure the units. The thumb nuts should only be hand
tight.
Connect the Deutsch mating part into the housing.
WARNING: Do not over tighten the studs/thumb nuts and don’t use metal screws
as they may damage the unit and void the warranty.
™
™
