5.8 Menu schematic for a Profibus PA sensor
(example: VEGAFLEX 61)
Information:
Depending on the version and application, the highlighted
menu windows are not always available.
Basic adjustment
1
▶ Basic adjustment
Indication
Diagnostics
Service
Info
1.1
Sensor address
000
1.2
Min. adjustment
0.00 %
=
10,000 m(d)
8,000 m(d)
1.3
Min. adjustment
100.00 %
=
1,000 m(d)
2,000 m(d)
1.4
Linearisation curve
linear
1.5
Channel
PV lin. value
1.6
Damping
0 s
1.7
Sensor-TAG
Sensor
Indication
2
Basic adjustment
▶ Indication
Diagnostics
Service
Info
2.1
Displayed value
Primary Value
Diagnostics
3
Basic adjustment
Indication
▶ Diagnostics
Service
Info
Setup
