veise TK001 - TK001 Deadbolt Interior Assembly Mounting

C
Unlocked
Keep the thumb turn in vertical position and install
the interior assembly.
Install interior assembly
4
STEP
Do not load batteries until lock is
completely installed.
IMPORTANT:
Push the battery cover out in
the direction as illustrated.
Insert the cable
connector to the
socket. Push the
connector in firmly
until it is completely
attached.
Attach Interior
Assembly to
Mounting Plate and
tighten 3 Screws.
A B
D
11
Horizontal
Interior Assembly
Screws (K)
or
