DVM1200 VELLEMAN
- 11 -
AC Voltage
Range
Resolution
Accuracy
600mV
0.1mV
± (3.0% of rdg ± 3 digits) (manual)
6V
1mV
± (1.0% of rdg ± 3 digits)
60V
10mV
600V
100mV
700V
1V
± (1.5% of rdg ± 3 digits)
1
Frequency Range for ACV: 40Hz~400Hz
2
Response for ACV: avg, calibrated in RMS of sine wave
Overload protection: 1,000VDC or 700VAC RMS
Input impedance (nominal): > 10MΩ; AC voltage: > 10MΩ
Common mode rejection ratio: DC voltage: > 100dB @ DC, 50 or 60Hz; AC voltage: > 60dB @ DC, 50 or 60Hz
Normal mode rejection ratio: DC voltage: > 45dB @ 50 or 60Hz
Frequency
Range
Resolution
Accuracy
99.99Hz
0.01Hz
± (0.1% of rdg ± 3 digits)
999.9Hz
0.1Hz
9.999kHz
0.001kHz
99.99kHz
0.01kHz
999.9kHz
0.1kHz
Overload protection: 250VDC or 250VAC RMS
Resistance
Range
Resolution
Accuracy
600.0Ω
0.1Ω
± (0.5% of rdg ± 3 digits)
6.000kΩ
1Ω
± (0.5% of rdg ± 2 digits)
60.00kΩ
10Ω
600.0kΩ
100Ω
6.000MΩ
1kΩ
60.00MΩ
10kΩ
± (1.5% of rdg ± 3 digits)
Overload protection: 250VDC or 250VAC RMS
Diode Test
Range
Resolution
Accuracy
1V
0.001V
1.0% uncertainty
Forward DC Current: ± 1mA
Reverse DC Voltage: ± 1.5V
Overload Protection: 250VDC or 250VAC RMS
Continuity Check
Range
Resolution
Accuracy
600Ω
0.1Ω
Open circuit voltage approx. 0.5V
Continuity beeper: ≤ 50Ω
Overload Protection: 250VDC or 250VAC RMS
