Velleman EMDIN02 User Manual

EMDIN02
V. 08 – 16/08/2018 3 ©Velleman nv
techniques, LSI circuits and advanced digital and SMT techniques.
The meter is in conformity with the relevant technical requirements
of Class 1, Class 2 and IEC62052-11, IEC62053-21. It accurately and
directly measures 50/60 Hz active energy consumption from single
phase AC electricity net.
Features
 LCD display (with blue backlight)
 pulse output
 LED indicator
Reset
To reset the device, keep your finger on the infrared eye (marked
Reset) for 3 to 12 seconds.
The upper row will reset to zero.
The lower row shows the total of kW/h permanently.
Connections
Refer to the illustrations on page 1 of this manual.
 20-21: counter outputs (see technical specifications for details)
 23-24: not used
Technical Specifications
voltage
230 V
current
5 (80) A
(1)
accuracy class
1.0
frequency
50 / 60 Hz
display mode
LCD 5+1 = 99999.9 kWh
power consumption
≤ 0.4 W (8 VA)
temperature range
-20 to 65 °C
LED indicator
1 blink per pulse
pulse output
1000 imp/kWh
voltage: 12 to 27 V
current: 27 mA
impulse width: 90 ms

Velleman EMDIN02 Specifications

General

Brand	Velleman
Model	EMDIN02
Category	Measuring Instruments
Language	English
