2
Features:
For visualization of audio signals.
Use with mixing panels, amplifiers, car audio systems…
Easily connects to the line-level output (LOW INPUT) from any tape deck, stereo system, or CD player.
A special input (HIGH INPUT) is provided, so that the unit can directly be connected to the speaker
output of most systems*.
To make it universal, the readout can be set as DOT or BAR indication.
The supplied display window for vertical or horizontal mounting, makes the unit very attractive.
Specifications:
Bar or dot readout.
Scale: -23dB to +5dB, 15 LED’s per channel.
dB-linear division from -4 to +5dB (1dB per led).
Systematically growing steps below -4dB.
Accuracy: ±0.5dB (1KHz).
Frequency range: 20Hz to 30KHz (-3dB).
Three different LED colors: green, orange and red.
Adjustable input sensitivity: 150mV to 5Vrms Low input
1.5V to 50Vrms High input
Input impedance: 47K Low input / 470K High input
Power supply: 12 to 15VDC / 300mA
Dimensions: 150 x 57mm
NOT SUITED FOR CONNECTION TO HIGH POWER CAR STEREO SYSTEM
