K8403USER MANUAL
What’s in the box
1.
2.
3.
4.
5.
1. 4x LED strip 20 cm
2. 8x clips
3. 8x double-sided tapes
4. 3x short cables (2 connectors)
g. 1
What’s on the PCB
1.2.
3.
4.
5.
1. 3x 330 Ω resistors
2. 3x 2V7 1.3 W zener diodes
3. 3x BUK9535-55 logic level FETs
4. 2x 2 pole screw terminals
5. 2x 6P female headers (14.5 mm pins)
g. 2
6. 2x 6P female headers (5 mm pins)
for connection on the motherboard
6.
5.
5. 1x long white cable
(1 connector)
6. 1x long coloured cable
(no connector)
7. 4x shrink tubes
