PCS500 / PCS100 / K8031
23
View Menu
Markers
Two horizontal markers for measuring voltage
Note: The voltage markers give preference to channel Ch1 if both channels
are being used.
Two vertical markers for measuring time
Marker function for absolute and relative time measurement is provided.
If V & t markers are selected the absolute time of the marker position is
displayed.
If V & dt markers are selected the time difference between the markers is
displayed.
Moving the markers
Place the mouse pointer over a dashed marker line.
Press and hold the left mouse button. The marker line turns solid.
Drag the marker to the appropriate position
Bright Grid
Brightens the blue grid on the screen.
Help Menu
Contents
Displays the help file (English only)
About
Displays information of the program version
