4
VM130USER MANUAL
Specications
• power supply : 9 to 13 Vac or 10 to 15 Vdc / 130 mA max.
• selectable timers per output: 0.5, 5, 30 s / 1, 5, 15, 30, 60 min
• open eld range of up to 30 m
Receiver:
Transmitter:
• 12 V battery type: V23GA, GP23GA...
• CE compliant 433 MHz operation
• over 1.000.000.000 combinations
Features
• two relay contact outputs (5 A resistive load)
• ON/OFF (toggle) or timer-mode (pulse)
• learning unique 32-bit random code
• up to 31 different transmitters can be stored
• code memory can be erased for safety purposes
• internal heating option for cold environment
Transmitter instructions
The transmitter comes with a factory set default code.
Open the enclosure:
SW1
LED
SW2
SW3
SW1 = CHANNEL 1, SW2= CHANNEL 2
