Velleman WS8472 - Page 5

WS8472
V. 01 – 10/06/2015 5 ©Velleman nv
DIP Switch Table
DIP switch
channel
1
2
3
4
down
down
down
/
1
down
down
up
/
2
down
up
down
/
3
down
up
up
/
4
up
down
down
/
5
up
down
up
/
6
up
up
down
/
7
up
up
up
/
8
/
/
/
down
°F
/
/
/
up
°C
7. Installation
We recommend mounting the sensor on a
sheltered and shaded, north-facing wall.
Use a screw or nail (not included) to affix
the sensor as shown in the picture.
8. Pairing the Thermo-/Hygrometer with the
Sensor
8.1 Pairing
1. Move the sensor about 2 m away from the thermo-/hygrometer. If you
are using more than one sensor, make sure they are all powered up
and transmitting on a different channel.
