Vendo VDI 100 User Manual

Instruction for installation,
maintenance technician
and final user.
VENDING MACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 8 di 46
MODELS
100 189 217 254
Dimensions
Height (A) 1425 mm 1830mm 1830 mm 1830 mm
Width (B) 705 mm 705 mm 853 mm 1010 mm
Depth (C) 745 mm 745 mm 745 mm 745 mm
Weight 186 Kg 235 Kg 264 Kg 294 Kg
Electrical particulars
Nominal voltage 230/240 Vac 230/240 Vac 230/240 Vac 230/240 Vac
Nominal frequency 50 Hz 50 Hz 50 Hz 50 Hz
Installed power 450 W 600 W 450 W 450 W
Machinery noise Lower than 70 dB Lower than 70 dB Lower than 70 dB Lower than 70 dB
Cooling system
Compressor 5,67 cm³ 8,85 cm³ 8,85 cm³ 8,85 cm³
Refrigerator power 260 W 260 W 474 W
474 W (-5°C -
+55°C)
Expansion Direct with capillary Direct with capillary Direct with capillary Direct with capillary
Cooling
Forced circulation by
means of one fan
Forced circulation by
means of one fan
Forced circulation by
means of one fan
Forced circulation by
means of two fans
Working range
10°C / 32°C
65% RH
10°C / 32°C
65% RH
10°C / 32°C
65% RH
10°C / 32°C
65% RH
Settable temperature
range
0°C y15 °C 0 °C y15 °C 0 °C y15 °C 0 °C y15 °C
Coolant R134A R134A R134A R134A
Load 0,200 Kg 0,220 Kg 0,220 Kg 0,220 Kg
