TECHNICAL FEATURES
Power supply 13.8 Vdc
Minimum supply voltage 10 Vdc
Maximum supply voltage 16 Vdc
Max consumption in alarm 170 mA (350 mA max) +/-10 mA
Max consumption in pre-alarm 80 mA (100 mA max) +/-10 mA
Settable consumption and sound power Consumption from 20 mA to 170 mA
Max LED Flashing Unit consumption
Terminals 1, 2 (L models only)
12 mA
Max audio level SPL @1 m See diagram 1
8 sounds
3 modulated, 3 intermittent, 1 bi-tone, 1
continuous
Available timings Infinite or 8 minutes
Double micro-switch tamper Anti-opening and anti-removal
Working condition From -25 °C to +50 °C
Environmental class II
Security Grade 3
IP degree IP4x
Standards
compliance
Certifying body
(IMQ-SISTEMI DI SICUREZZA)
T031:2017 + A1:2018
EN50131-4:2019
Size (HxWxD) 155x100x53 mm
Weight 240 gr
