Page 16
Installation and Operation Manual - HEI170
ENGLISH
4. Operating the Insert
Before using the insert, the following steps should be completed :
• Empty the combustion chamber and install the air control handle (A):
Empty the combustion chamber Installing the air control wood handle
• Install the combustion chamber side bricks as shown below.
Install the Combustion Chamber Bricks Combustion Chamber Bricks Layout
• Install the ash lip and the blower (see «Appendix 1: Blower and Ash Lip Installation»);
• Install the faceplate (See «Appendix 2: Faceplate Installation»).
The following step is optional :
• Install the fresh air intake (See «Appendix 3: Optional Fresh Air Intake Kit Installation»).
This wood heater has a manufacturer-set minimum low burn rate that
must not be altered. It is against federal regulations to alter this setting or
otherwise operate this wood heater in a manner inconsistent with operating
instructions in this manual.
