Page 25
Installation and Operation Manual - HEI170
ENGLISH
5. Peel off more of the backing and rotate the glass. The gasket must not be stretched during
installation.
6. Cut the gasket to the required length.
7. Pinch the gasket onto the glass in a U shape, all around the glass.
6.3 Door
In order for the stove to burn at its best efficiency, the door must
provide a perfect seal with the firebox. The tightness of the door
seal can be verified by closing and latching the door on a strip
of paper. The test must be performed all around the door. If the
paper slips out easily anywhere, either adjust the door or replace
the gasket.
6.3.1 Adjustment
The gasket seal may be improved with a simple latch mechanism adjustment:
1. Remove the split pin by pulling and turning it using pliers.
2. Turn the handle one counterclockwise turn to increase pressure.
3. Reinstall the split pin with a small hammer.
Removing the retaining pin Reinstalling the retaining pin
