Installation and Operation Manual - HEI170
ENGLISH
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for this unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 AC07868 1/2" BLACK COIL HANDLE 1
2 AC09185 DOOR LATCH KIT 1
3 SE70697 REPLACEMENT HANDLE WITH LATCH KIT 1
4 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
5 SE24328 VENTIS SERIAL 1.7 CAST IRON DOOR 1
6 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L 1
7 AC06400 3/4" (FLAT) X 6' BLACK SELF-ADHESIVE GLASS GASKET 1
8 SE70789 VENTIS 1.7 GLASS 1
9 PL70884 RIGHT GLASS FRAME 2
10 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
11 30507 BLACK TORX SCREW WITH FLAT HEAD TYPE F 1/4-20 X 3/4" 3
12 SE70798 ASH SHELF 1
13 PL70665 DECORATIVE PANEL 2
14 30337 SQUARE HEAD SET SCREW 1/2-13 X 1-3/4" 2
15 PL70587 FACEPLATE EXTENSION 1
16 PL34052 LINER FIXATION BRACKET 3
17 29015 4'' X 9'' X 1 1/4'' REFRACTORY BRICK 12
18 29010 4 1/2" X 9" X 1 1/4" REFRACTORY BRICK 4
19 PL36031 3 5/8" X 9'' X 1 1/4'' REFRACTORY BRICK 1
20 PL70516 SECONDARY AIR TUBE 4
21 21586 VERMICULITE 1
22 VBA1556 FACEPLATE - 32 X 50 HEI150 1
23 PL65325 32 X 50 FACEPLATE TOP 1
24 PL65326 32 X 50 FACEPLATE SIDE 2
25 VBA1555 FACEPLATE - 29 x 44 HEI150 1
26 PL65323 29 X 44 FACEPLATE TOP 1
27 PL65324 29 X 44 FACEPLATE SIDE 2
28 AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL 1
29 SE46165 HEI170 INSTRUCTION MANUAL KIT 1
30 AC01299 RIGID FIRE SCREEN 1
31 30898 ROUND WOODEN BLACK HANDLE DULL BLACK FINISH 2
32 SE70714 BLOWER ASSEMBLY 1
33 60013 POWER CORD 96" X 18-3 type SJT (50 pcs per carton) 1
34 44089 DOUBLE CAGE BLOWER 144 CFM 115V - 60Hz - 1.1A 1
35 44028 CERAMIC THERMODISC F110-20F 1
36 44085 RHEOSTAT KNOB 1
37 44087 RHEOSTAT NUT 1
