8. Hydraulic diagram
A. hydraulic diagram of the VRG-10
B. hydraulic diagram of the VRG-20 and 25 without a 6/2 valve
C. hydraulic diagram of the VRG-20 and 25 with a 6/2 valve (see next page)
P1 P2
P3 P4 P1 P2
P4 P3
A. hydraulic diagram of the VRG-05 and 10
B. hydraulic diagram of the VRG-20 and 25 without a 6/2 valve
