VeriFone MX800 Series Ethernet Installation

3 | P a g e
Connecting the Hardware
Before you begin, make sure your Verifone MX800 series
pinpad is plugged in and properly connected to your
router/switch via a network cable.
You can connect your Verifone MX800 series pinpad to your PC
through either a router or a switch via cat-5e cable (see image
below).
NOTE: WHILE THE DEVICE WILL PHYSCIALLY BE ABLE TO BE ACCESSED BY EVERY COMPUTER OVER THE
NETWORK WITH AN ETHERNET CONNECTION, THE PINPAD MAY ONLY BE INTERFACED WITH ONE COMPUTER AT
A TIME!
