VeriFone MX800 Series Installation

8 | P a g e
Enabling the Firmware Update Download on the PinPad and Beginning the Download in CRE/RPE
1. At the System Mode screen select FILE TRANSFER.
2. At the File Transfer screen select DOWNLOAD.
3. While on the Configure Direct Download screen
select the Port that the PinPad is connected to
(Note: If using a serial cable to perform the update,
the COM port will be COM3).
4. Under Baud Rate? Leave as the default (115200).
5. Under Download Type?:
 If either the OS (Step 1*) or PCA (Steps 4 & 5*)
update is being performed select Full.
 If either the SP (Step 2*) or SP (Step 3*) update
is being performed select Partial.
* From the Grid on Page 12
6. Select GO! To begin the file transfer.
