Verint Video Solutions 3
Nextiva Multiport S17XXe Series User Guide
For more information about this security feature, refer to the SConfigurator User Guide.
Video
The S1704e-AS, S1708e, and S1708e-AS devices provide DVD-quality video resolution,
whereas the S1712e and S1724e transmitters offer a cost effective, high port count
solution.
On the S1704e-AS, S1708e, S1708e-AS, and S1712e devices, the video stream for each
input is sent to two encoders; on the S1724e, it is sent to a single encoder.
The video frame rate of the edge device can be:
NTSC—1 to 7, 10, 15, or 30 frames per second (fps)
PAL—1 to 6, 8, 12, or 25 fps
All transmitters in the S17XXe series can have the following video resolutions:
The maximum frame rates (in frames per second) for the proprietary MPEG-4-based
compression mode are, using the NTSC (PAL) format:
The maximum frame rates (in frames per second) for the MPEG-4 ISO 14496-2 compliant
compression mode are, using the NTSC (PAL) format:
Resolution Number of columns Number of lines
NTSC/PAL NTSC PAL
CIF 352 240 288
2CIFH 704 240 288
4CIF 704 480 576
All lines 352 480 576
2/3 D1 480 480 576
VGA 640 480 576
Resolution MPEG-4-based mode
S1704e-AS S1708e S1708e-AS S1712e S1724e
CIF 30 (25) 30 (25) 30 (25) 30 (25)
15 (12.5)
2CIFH 30 (25) 30 (25) 30 (25)
30 (25)
7.5 (6.25)
4CIF 30 (25) 30 (25) 30 (25) 15 (12.5) 3.75 (3.125)
All lines 30 (25) 30 (25) 30 (25) 30 (25) 7.5 (6.25)
2/3 D1 30 (25) 30 (25) 30 (25) 15 (12.5) 7.5 (6.25)
VGA 30 (25) 30 (25) 30 (25) 15 (12.5) 3.75 (3.125)
Resolution MPEG-4 ISO 14496-2 compliant mode
S1704e-AS S1708e S1708e-AS S1712e S1724e
CIF 30 (25) 30 (25) 30 (25) 30 (25) 30 (25)
2CIFH 30 (25) 30 (25) 30 (25) 30 (25) 7.5 (6.25)
4CIF 30 (25) 30 (25) 30 (25) 15 (12.5) 3.75 (3.125)
All lines 30 (25) 30 (25) 30 (25) 15 (12.5) 7.5 (6.25)
2/3 D1 30 (25) 30 (25) 30 (25) 15 (12.5) 7.5 (6.25)
VGA 30 (25) 30 (25) 30 (25) 15 (12.5) 7.5 (6.25)
