1. Loosen the fixing screws (2), if necessary.
2. Erect both slatted frames (1) and insert them into each other.
3. Retighten the fixing screws (2) of the slatted frame connection.
3.2.3 Wooden side rails
Adjust the bed to medium height. If the bed is adjusted too low, it is not possible to mount the side
rails; if it is adjusted too high, you have to pull the side rails too far upwards.
For Luna 2, Luna Basic 2
Risk of injuries
 The side rails can be mounted in a high or low position.
Place the side rails in the lowest position
when the slatted frame is mounted in the lowest height.
WARNING
6
5
1 = Highest position
2 = Lowest position
1 = Bolt rails
2 = Wood slats (2 pieces each side)
3 = Sliding rail
4 = Locknut
5 = Stop
6 = Screw
