Vermeiren Luna Basic 2 - 1.6 For your safety

Luna 2, Luna Basic 2, Luna UL 2
2021-03
Assembly
Installation manual
7
EN
NL
3.2 Assembling the bed
Risk of injuries
 Keep your fingers and the electric cables away from moving parts, and make sure that they do
not become trapped between components during assembly.
 No third persons or any objects may come in the assembly area.
Follow the order of assembly as explained below.
3.2.1 Head panel / feet panel
1. Mount the attachment of the slatted frame (3) on the attachment of the head panel (4).
2. Secure the slatted frame (1) with the locking clamps (5).
3. Repeat for the feet panel. Check that the slatted frames are mounted very well.
The slatted frame can be mounted in 2 different positions (Ⓑ, Ⓒ): step 64 mm (not for Luna UL
2).
3.2.2 Slatted Frame
CAUTION
1 = Slatted frames
2 = Fixing screws
1 = Slatted frame
2 = Head and foot panels
3 = Attachment slatted frame
4 = Attachment panels
5 = Locking clamp
