Vermona RETROVERB - CV; Pedal and Trigger Inputs

- Page 9 -
OUTPUT
The Outputs L / R are mono jacks. The signal on the right channel is phase reversed in modes 2 and 4,
CV / Pedal and Trigger Inputs
CV / PEDAL
You can connect an external control voltage or an
expression / volume pedal to this jack for controlling
the CUTOFF frequency of the filter. The intensity
can be adjusted with the corresponding INT
trimmer.
For connecting a CV source i.e. from a modular system or an analogue synthesizer, you need a simple mono
cable:
To connect a Volume pedal a Y-cable is necessary:
Audio Trigger / GATE
These inputs are responsible for triggering the CRASH function or the ENVELOPE GENERATOR. They work
either with a GATE signal with positive flank (i.e. from a modular system) or with an audio signal.
If you would like to trigger the corresponding function with an audio signal you should use short, percussive
signals. The sensitivity can be set with the corresponding trimmer.
Trimmer
The trimmers can be adjusted with a small screw driver.
The more you set the trimmer clockwise, the higher the intensity/sensitivity.
Check the settings of the trimmers if any of these functions do not work correctly.
