Vermont Castings Intrepid INDVR Series User Manual

5 20012761
24¹⁄₄”
(616 mm)
13¹¹⁄₁₆” (347 mm)
21³⁄₁₆” (538 mm)
13⁷⁄₈” (352 mm)
21³⁄₄” (553 mm)
16⁷⁄₁₆”
(418 mm)
21³⁄₈"
(543 mm)
18”
(457 mm)
Centerline
of Flue Pipe
12761
Intrepid DV
dimensions
6/07
6¹⁄₂”
(165 mm)
C
L
Valve
Inlet
4”
(102 mm)
C
L
Valve Inlet
Stove Dimensions - Intrepid Direct Vent Gas Heater
Figure 1 - Intrepid dimensions.

Vermont Castings Intrepid INDVR Series Specifications

General

Brand	Vermont Castings
Model	Intrepid INDVR Series
Category	Gas Heater
Language	English
