r
 UploadthecongurationdatafromtheVX-450totheComputerbythe“Upload”param-
eterinthe“Radio”menutab.
r
 Click the left mouse button on the large
[SETUP]button,thenseteachparameteron
the“SETUP”tab.Refertothe CE104Help
les regardingthedetailsofthe functionof
eachparameter.
r
 Whennishedchangingthesettings,down-
load the configuration datafromthe Com-
putertotheVX-450byselectingthe“Down-
load”parameterinthe“Radio”menutab.
r
 Programmingisnowcomplete.Performthe
alignment of the ManDown sensor of the
DVS-9,ifneeded.
dVs-9 unit adjustment
(
using ce104
)
Important note:TheDVS-9isadjustedatthefactory.Therefore,theDVS-9doesnotneed
adjustmentnormally.AdjusttheDVS-9whentheoperationisabnormal.
r
 Place(notlaydown)theVX-450onahori-
zontalsurface.
r
 Click the left mouse button on the large
[ALIGNMENT]button,thenclickthe[START]
buttontoopenthe“AngleInitialize”window.
r
 Clicktheleftmousebuttononthe[OK]but-
tontoinitiatethealignment.
r
 Whenthealignmentissuccessful,clickthe
leftmousebuttononthe[OK]buttontoter-
minatethealignment.
r
 Alignment is now complete. Close the
CE104ProgrammingSoftwareandturnofftheVX-450by
rotatingtheVOL/PWRknobfullycounter-clockwise.
prOgramming
TheCE104andCE115 ProgrammingSoftwareare neededtoprogramtheDVS-9.Install
theCE104andCE115toyourcomputerinadvance.
transceiVer prOgramming
(
using ce115
)
r
 Connect theVX-450transceiver(withtheDVS-9 installed)to your computer with the
FIF-10AUSBProgrammingInterface andCT-106ProgrammingCableortheCT-42A
ProgrammingCable.
r
 ExecutetheCE115ProgrammingSoftware,thenuploadthecongurationdatafromthe
VX-450totheComputerbyselectingthe“Upload”parameterinthe“Radio”menutab.
r
 Clicktheleftmousebuttononthe“KeyFunction”param-
eterinthe“Common”menutabtoopenthe“KeyFunction”
window.
r
 Assignthe“OptionSW2”(foractivating/disablingthe“Man
Down”function),assignthe“REC”, and“PLAY”functions
tothedesiredkeys,thenclickthe[OK]buttontoclosethe
“KeyFunction”window.
r
 If you want to edit the “Emergency” parameter after the
“Man Down” functionis activated,select
the “Emergency”parameterinthe“Com-
mon”menutab.RefertotheCE115Help
lesregardingthedetailsofthefunctionof
each parameter.Whennishedchanging
thesettings,clickthe[OK]buttontoclose
the“Emergency”window.
r
 Clicktheleftmousebuttononthe“Option”param-
eterinthe“Common”menutabtoopenthe“Option”
window.Conrmthe“OptionUnit”parameterisset
to“DVS-9”.
r
 Seteachparameterofthe“RECMode”,“PlayPri-
ority”,and“PowerONREC”tothedesiredfunction,thenclickthe[OK]buttontoclose
the“Option”window.RefertotheCE115Helplesregardingthedetailsofthefunction
ofeachparameter.
r
 When nishedchanging thesettings,downloadthe congurationdatafromthe Com-
putertotheVX-450byselectingthe“Download”parameterinthe“Radio”menutab.
r
 ClosetheCE115ProgrammingSoftwareandturnofftheVX-450.
dVs-9 unit prOgramming
(
using ce104
)
r
 ExecutetheCE104ProgrammingSoftware.
r
 RotatetheVOL/PWRknobclockwisewhilepressingandholdingtheTOPSELandPTT
keystoturnontheVX-450inthe“SubClone”mode.
 IntheVX-451,aseriesofbeepswillbeheardtoindicatetheradioisinthe“SubClone”
mode.
 IntheVX-454/-459, the“SUBCLONE”notation will appearonthe
displayandaseriesofbeepswillbeheardtoindicatetheradioisin
the“SubClone”mode.
adVice
ThereferencedirectionoftheDVS-9sensoristhesamedirectionofthesettingsta-
tusoftheVX-450whenyouadjustedit.
Forexample,IfyouadjusttheVX-450inthestatusthatlayitdown,referencedirec-
tionoftheDVS-9sensorbecomeshorizontal.
- 3 -- 2 -
