5
Operating Manual Reprint
Description of Operating Functions
Call/Reset
When the 2-tone selective calling unit is installed, press
the assigned Soft key to silence the receiver and reset for
another call, when a communication is finished.
Speed Dial
Your Dealer may have pre-programmed Auto-Dial tele-
phone number memories into your radio.
To dial a number, just press the Dealer-assigned Soft key
for Speed Dialing. The DTMF tones sent during the dial-
ing sequence will be heard in the speaker.
Accessories & Options
FNB-64 7.2 V 700 mAh Ni-Cd Battery
FNB-V57 7.2 V 1100 mAh Ni-Cd Battery
FBA-25 Alkaline Battery Case
NC-77B 120 VAC Overnight Desktop Charger
NC-77C 230-240 VAC Overnight Desktop Charger
VAC-800 Desktop Rapid Charger
VAC-6800 6-unit Multi Charger
MH-45B4B Speaker/Microphone
MH-37A4B Earpiece Microphone
VC-25 VOX Headset
VCM-1 Mobile Mounting Bracket (for VAC-800)
LCC-160/S Leather Case (for VX-160)
LCC-180/S Leather Case (for VX-180)
CT-42 PC Programming Cable
CT-27 Radio to Radio Programming Cable
CE44 Programming Software
TX Save Off
Press the assigned Soft key to disable the Transmit Bat-
tery Saver, if you are operating in a location where high
power is almost always needed.
The Transmit Battery Saver helps extend battery life by
reducing transmit power when a very strong signal from
an apparently nearby station is being received. Under some
circumstances, though, your hand-held radio may not be
heard well at the other end of the communication path,
and high power may be necessary at all times.
